AX6686-36V, 200mA LDO


AX6686-36V, 200mA Low Dropout Voltage Linear Regulator DataSheet

GENERAL DESCRIPTION
TheAX6686series are a group of low-dropout (LDO) voltage regulators offering thebenefits of wide input voltage range, low dropout voltage, low power consumption, andminiaturized packaging.
Quiescent current of only 2.2µA makes these devices ideal for powering thebattery-powered, always-on systems that require very little idle-state power dissipation to alonger service life. There is an option of shutdown mode by selecting the partswith the ENpin and pulling it low. The shutdown current in this mode goes down to only 10nA (typical).
TheAX6686series of linear regulators are stable with the ceramic output capacitor overits wide input range from 2V to 36V and the entire range of output load current (0mA to200mA).

FEATURES
-2.2μA Ground Current at no Load
-±2% Output Accuracy
-200mA Output Current
-10nA Disable Current
-Wide Operating Input Voltage Range: 2V to 36V
-Dropout Voltage: 0.65V at 100mA/ VIN 5V
-Support Fixed Output Voltage 3.3V, 5V.
-Stable with Ceramic or Tantalum Capacitor
-Current Limit Protection
-Over-Temperature Protection
-SOT-23-5,SOT-23-3,SOT-89-3Package Available
-RoHS and Halogen free compliance.
